IDIS DR-1204P DirectIP 1200 Series 4 Channel Full HD Recorder

Technical Specification

Features:

Make: IDIS
Model code: DR-1204P
Series: DR-1000 Series
Recording Mode: Real Time / Timelapse / Event
Video inputs: 4

Additional info:

Total incoming throughput 84Mbps Up to 120ips Full HD real-time recording Up to 120ips live display Easy to install, set-up, and play with DirectIP cameras Built-in 4 channel PoE Switch Expandable up to 4TB

Contact manufacturer Datasheet

Make	IDIS
Category	Surveillance software products
Model code	DR-1204P
Series	DR-1000 Series
	Recording Mode: Real Time / Timelapse / Event Video inputs: 4 Inbuilt multiplexer: 1 Recording system: HDD Storage capacity: 4 TB Secondary storage: USB Storage rate: 120 ips Resolution: 1920 x 1200 Operating system: Embedded Linux
Electrical Specifications	Voltage: 56 V DC Power consumption (W): 39 W
Physical Specifications	Weight (kg): 1.2 Dimensions (mm): 215 x 45 x 217
Environmental Specifications	Operating temperature (°C): 0 ~ 40 C (32 ~ 104 F) Operating humidity (%): 0 ~ 90
Additional info	Total incoming throughput 84Mbps Up to 120ips Full HD real-time recording Up to 120ips live display Easy to install, set-up, and play with DirectIP cameras Built-in 4 channel PoE Switch Expandable up to 4TB
